Everlight Moran®
A semi-closed cell foam with EPDM synthetic rubber as main component, with excellent heat, weather and chemical resistance (Everlight Moran #031 is a self-standing foam). Its flexibility allows it to easily follow uneven surfaces, can be easily compressed, exhibits stable water and air sealing properties and is used in a wide range of industrial fields. The unique foaming technology allows a line-up of grades ranging from approximately 10 to 25 times, with the 25-times foamed product in particular being a rare material in the world.
Furthermore, it is free from halogens, heavy metals such as lead and cadmium, and bituminous materials such as bitumen, eliminating the risk of contamination. Despite being flame retardant-free, #730 and #830 are UL-94 HBF certified.
Main applications
- ・Mirror mounting
- ・Soundproofing materials for DVD enclosures
- ・Waterproofing, air tightness and insulation of air conditioners and car air conditioners
- ・Airtight materials around radiators and condensers
- ・Soundproofing material inside pillars.
- ・In building and civil engineering components for insulation purposes.
Standard product specifications
| material | Thickness（mm） | Width（mm） | Length（mm） | Features |
|---|---|---|---|---|
| Everlight Moran＃730 |
3、5、8、10、15、20、25、30、35、40 | 1000 | 2000 | High watertight type |
| Everlight Moran＃830 |
3、5、8、10、15、20、25、30、35、40 | General-purpose type | ||
| Everlight Moran＃930 |
5、8、10、15、20 | Low hardness type | ||
| Everlight Moran＃A30 |
5、8、10、15、20 | Low hardness watertight type | ||
| Everlight Moran＃031 |
3、5、8、10、15 | rubber sponge opposition |
Adhesive specifications
| material | Adhesive type | stiffener type | construction |
|---|---|---|---|
| R801 | Acrylic type | Fabric |  |
| R811 | High strength non-woven fabric | ||
| R910N | Butyl type | Fabric |
※For R910N, the length is 1000 mm (width) x 1000 mm (length).
special characteristic
| material | density（kg/m3） | tensile strength（KPa） | growth（％） | 70°C 50% compression set（%） | 50% compression Hardness（kPa） | watertightness（50% compression.50mm water height） | watertightness（80% compression, 100 mm water height） |
|---|---|---|---|---|---|---|---|
| Everlight Moran＃730 |
120 | 89 | 277 | 23.0 | 4.9 | ○ | ○ |
| Everlight Moran＃830 |
100 | 70 | 253 | 22.1 | 3.9 | ○ | ○ |
| Everlight Moran＃930 |
55 | 50 | 217 | 26.1 | 1.0 | × | △ |
| Everlight Moran＃A30 |
51 | 47 | 184 | 23.6 | 1.2 | – | ○ |
| Everlight Moran＃031 |
102 | 121 | 328 | – | 55 | ○ | ○ |
※ ○: No leakage for more than 24 hr △: No leakage for 30 min ×: Leakage within 10 min (Values are measured values, not guaranteed values).
※ Measuring method: a 10 mm wide sample punched out in a U-shape is sandwiched between two transparent acrylic plates and a PP film, left to stand for one day and night, and then filled to the prescribed water level. Allow to stand still and measure the time it takes for the water to start leaking.
